Part# Description
WNASA469 46 grit roughing wheel
WNABA4639 46/60 grit roughing wheel
GW204N 60 grit general purpose wheel
GW292N 60 grit general purpose wheel
GW202 220 grit finishing wheel
GW203 60 grit general purpose wheel
GW271C Ceramic general purpose wheel
WNAWA462 Roughing wheel for Weinig grinders
WNAWA100 Finishing wheel for Weinig grinders
Click here for NXU522 Diamond Dresser & WSC9951-G Grinder Coolant

Probe Setting Stands

Cutterhead set-up device with interchangeable arbors and digital readout on probe. Makes proper knife set-up fast, easy and accurate.

Capacities: Swing Arm Diameter: 6.30" (160mm), 9" head length, 230mm

State Arbor Size Required when ordering.

Available arbor sizes include:
1-1/4", 35mm, 1-1/2", 40mm, 1-13/16", 50mm, 2-1/8"
Part # Description Price
CASS1025 Probe Setting Stands, State Arbor Size Required CALL

Template Material
Part# Description
NXT6 Steel Template Material 13” long.
NXT8 Cast Acrylic Template Material 13” long
NXT0124 True Straight -Knife Template 14” long
TBO650 Template Making Kit

140mm Body Diameter Steel Feed Wheels

Seen at left: GA4542 - Shaft Mount

NEW Resharpening Service - Call for details!
Part # Mount/Description Width Bore
GA4563 Flange 10mm 25mm
GA4562 Flange 20mm 25mm
GA4545 Flange 50mm 25mm
GA4544 Shaft 10mm 35mm
GA4542 Shaft 20mm 35mm
GA4569 Shaft 50mm 35mm
GA4564 Flange (bottom) 20mm 25mm

140mm Body Diameter Poly Feed Wheels

Replaceable Tire System -This picture is the GA0106H Hub with
GA0106T80 Tire mounted on it.

Part # Mount/Description Width Bore
Steel Hubs with Bonded Tires - Non-Replaceable Type NEW! We can recover your bonded tires- Call for details!
GEM3341 Flange 10mm 25mm
GEM3339 Flange 20mm 25mm
GA4432 Shaft w/Set Screws 50mm 25mm
The items listed below are the replaceable type.
GAO106H 20mm hub for replacement feed wheel - flange mount, no keyway 20mm 35mm
GAO106T80 20mm replacement poly feed wheel 20mm
GAO108HAS 50mm hub for poly replacement feed wheel, shaft mount 50mm 35mm
GAO108T80 50mm replacement poly feed wheel 50mm
